Move the tool
Slide the tool sideways across the wall. When the
maximum display appears, mark the position.
Tip 1: The position between the two markings is the mid-point
of the metal object. Through the high measuring sensitivity,
thick metal objects appear broader than they are in real life.
By calibrating once more (PRESS CAL), the sensitivity can be
reduced, and you can then begin measuring again nearer the
metal object. If need be, repeat the process. Alternatively,
reduce the measuring depth (SET button).
Tip 2: The position where you start is important: First place
the device in a position where you know there is no metal.
Otherwise, the message "ERROR" will appear in the display.
To remedy: Move the device to another position a few
centimetres away and start measuring again.
Tip 3: The maximum display does not light up, even though
the LC display shows a reading. As soon as the most intense
display appears, the tool is near to metal. Mark this point.
Alternatively, increase the measuring depth (SET button).
Tip 4: In the case of complicated applications, e.g. ribbed
steel, scan the surface both horizontally and vertically.
5 Measuring in STUD-SCAN mode
For electronically detecting studs and joists in dry walls (plaster
fibreboard, wooden panels and other non-metallic panelling).
Use the SET button (3) to adjust the measuring depth.
– Select STUD-SCAN (button 4), Standard setting.
This setting is ideal for plaster fibreboard panels installed
in one thickness (max. 1 cm).
– Select "Deep" (SET button) for two plaster fibreboard
panels installed on top of each other (max. 2 cm).
MultiFinder Pro
Then scan from the
other side.
