2 Start-up and calibration
Switch on the device (button 8). The device starts in
METAL-SCAN mode.
Auto-calibration: Calibration takes place automati-
cally in METAL-SCAN mode and in AC-SCAN mode.
The device can be re-calibrated by pressing the CAL button
(7). To achieve maximum sensitivity, hold the device in the
air while calibrating.
AutoShutOff: The device will automatically switch itself off
about 2 minutes after the last measurement.
3 Select measurement mode
Select METAL-SCAN, STUD-SCAN or AC-SCAN by pressing
4, 5 or 6.
4 Measuring in METAL-SCAN mode
For detecting metal in masonry and concrete walls. The tool is
able to detect hidden metal in all non-metallic materials, e.g.
brick, concrete, screed, wood, plaster fibreboard, gas concrete,
ceramic and mineral building materials. Use the SET button (3)
to adjust the measuring depth.
– Select METAL-SCAN (button 5), Standard setting. This setting
is suitable for iron and steel reinforcement elements that are
suspected near the surface.
– Select "Deep" or "S-Deep" for deeper objects to a depth of
max. 10 cm (SET button).
– Select "S-Deep" for copper pipes or copper electric wires
which are suspected to be near the surface – copper pipes
to a depth of max. 5 cm, electric wires to a depth of max.
3 cm. Flexible floor and wall heating pipes which contain
a metal foil and are located near the surface may also be
detected. Test for this function in places where you know
the position of such pipes.
– Now follow the instructions on the LC display.
– MOVE: Move the tool slowly across the surface.
!
IMPORTANT: The device must be in contact with the
wall all the time while scanning.
