– Select "S-Deep" (SET button) for thick wooden panels
and floor constructions (parquet etc.), max. measuring
depth 4 cm.
– Now follow the instructions on the LC display.
– ON WALL: Place the tool against the wall.
– PRESS CAL: Press the calibration button (7) and wait until
calibration is completed: cal ok.
– MOVE: Move the tool slowly across the surface.
!
IMPORTANT: The device must be in contact with the
wall all the time while scanning.
Move the tool
Slide the tool sideways across the wall. When
the maximum display appears, you have
reached the edge of the stud.
Tip 1: The position between the two markings is the mid-point
of the stud.
Tip 2: The position where you start is important: First place the
tool in a position where you know there is no stud. Otherwise,
the message "ERROR" will appear in the display. To remedy:
Move the tool to another position a few centimetres away
and start measuring again.
Tip 3: The maximum display does not light up, even though
the LC display shows a reading. As soon as the most intense
display appears, the tool is over the edge of the stud. Mark
this point. Alternatively, increase the measuring depth (SET
button).
Tip 4: To avoid interference while scanning, keep your
free hand and other objects at least 15 cm away from the
MultiFinder.
Tip 5: The MultiFinder will only find the outside edge of
double studs and headers which may be fitted around
doors, windows and corners.
12
GB
Then scan for the other
edge of the stud.
