Next Level Racing F-GT ELITE Bedienungsanleitung Seite 4

support@nextlevelracing.com
5 X END CAP 40X40 6 X END CAP ANGLED 40X80
68 X M8 16MM BOLT
8 X M8 45MM BOLT
16 X M8 16MM COUNTER SUNK BOLT
2 X M8 60MM BOLT
6 X M8 20MM COUNTER SUNK BOLT
86 X M8 WASHER
16 X M6 WASHER 12 X M8 110MM BOLT
16 X M6 15MM BOLT SEAT BRACKETS
6
3 X END CAP LEFT 40X100 3 X END CAP RIGHT 40X100
8 X M8 35MM BOLT 56 X M8 REGULAR T-NUTS
6 X M8 FLANGE NUT
8 X M6 FLANGE NUT 32 X M8 FULL WIDTH T-NUT
4 X ADJUSTABLE FEET 4 X SEAT SLIDER RATCHET HANDLES
2 X PEDAL ADJUSTMENT FINS 2 X PEDAL ARM BRACKETS
2 X PEDAL PLATES 4 X SEAT SLIDER TABS
SHIFTER PLATE
MOTION V3 MOUNTING BRACKETS
FRONT MOUNT BRACKET MOUNTING ARMS
4 X LOW PROFILE M8 25MM BOLT
10 X LOW PROFILE M8 14MM BOLT 14 X M8 NYLON WASHER
4 X STICKY FELT PAD
(WHEEL DECK SIDE MOUNT)
BUTT KICKER MOUNT POLE
RATCHET WRENCH SMALL LEVEL
Video Instruction: bit.ly/nlrbuild
3 X SHIFTER MOUNTING CORNER
SHIFTER EXTENSION PLATE BRACKETS
ALLEN KEYS/RATCHET PLASTIC KIT HOLDER
SIDE MOUNT BRACKETS SPACER PLATES
4 X FELT PAD 40MM X 35MM
4 X FELT PAD 60MM X 40 TEE UPRIGHT BRACKET PLATES
SAFETY STEP 8 X PLASTIC CABLE CLIP
1 X SPANNER
7
