21: Choose pedal angle
22: Bolt through support bars into T-Nuts previously installed in step 19
2 X M8 16mm bolt
2 X M8 washer
Repeat
on other
side
22
23: Install 4 x T-Nuts into the outside channels of the wheel posts on shifter side left or right from 1a or 1b
24: Install the shifter mounting corner brackets to the wheel post using T-Nuts previously installed in step 23
PARTS
25: Install 4 x T-Nuts into top and bottom channels of the medium shifter support arm
Video Instruction: bit.ly/nlrbuild
4 X M8 regular t-nut
4 X M8 16mm bolt
4 X M8 washer
4 X M8 regular t-nut
23
PARTS
PARTS
PARTS
