13b: Bolt through side mount brackets in to the wheel front mount plate
Note: Use level provided. Wheel bracket
must be kept flat and level during installation
to avoid skewing.
13c: Bolt through side mount brackets in to mounting arm
4 X low profile M8 14mm bolt
4 X M8 nylon washer
4 X low profile M8 25mm bolt
4 X M8 nylon washer
4 X M8 flange nut
16
PARTS
13d: Loosen bolt in the slot to adjust angle of wheel base
PARTS
13e: Tighten bolt in the slot to lock angle of wheel base
Video Instruction: bit.ly/nlrbuild
17
PARTS
NIL
PARTS
NIL
