15: Bolt pedal arm brackets to wheel post using T-Nuts previously installed in step 12a
16: Bolt through pedal arm brackets from step 15 with line markers facing up. Then install NLR end caps
17: Install 4 x T-Nuts into the top channel of each pedal plate arm (Red dots are T-nut placement)
4 X M8 16mm bolt
4 X M8 washer
2 X M8 60mm bolt
Note: Do not tighten the
2 X M8 flange nut
pedal bracket until you have
2 x M8 washer
your desired position
8 X M8 regular t-nut
Note: Use line laser lines for
easy alignment
20
PARTS
18: Bolt pedal plates to the pedal arms with
PARTS
19: Install 1 T-Nut into the inside channel of each pedal arm (Red dots are T-nut placement)
PARTS
20: Install pedal support bars on to base left and base right using T-Nuts installed in step 1a and 1b
Video Instruction: bit.ly/nlrbuild
Repeat
on other
slots* facing each other using T-Nuts previously installed on step 17
21
PARTS
8 X M8 16mm bolt
8 X M8 washer
side
PARTS
2 X M8 regular T-nut
PARTS
4 X M8 16mm bolt
4 X M8 washer
Repeat
on other
side
