*RECOMMENDED TOOLS
ALLEN KEYS
Note: Front piece has Next
Level Racing Logo
Back
02: Bolt front and back pieces to the base
Back
03: Repeat step 2 on opposite side
RATCHET WRENCH
4 X M8 45mm bolt
4 X M8 Washer
Front
Right
4 X M8 45mm bolt
4 X M8 Washer
Front
Front
Right
12
Note: Height of the foot can be adjusted only
when it's installed on to the the cockpit
04: Install feet
PARTS
05: Slide T-nut in to bottom channel
PARTS
07: Align tab on the foot inside the channel
Video Instruction: bit.ly/nlrbuild
4 X Adjustable feet
4 X regular t-nut
Note: Foot alignment tab
should sit in the channel
06: Screw foot in to T-nut installed in step 5
08: Tighten screw inside the foot with allen key
to lock the height
13
PARTS
