1. Motor not properly fixed.
2. Hood not properly fixed.
1. Too much distance hood-hob.
2. Too much draught because of open
doors and/or windows.
1. Screws are not firmly tightened.
2. The mounting bracket / mounting
plate is not fixed firmly.
If the appliance has a malfunction not noted on the schedule or if you have
checked all items on the schedule but the problem still exists, please
contact the aftersales service.
I
F THE HOOD DOES NOT WORK PROPERLY AND
INCREASED OPERATING NOISE
 Incorrect dimension of the air duct.
 Obstruction in the air duct.
 The diameter of the air duct from hood to wall-box inclusive should be
120 / 150 mm; otherwise the capacity of the motor may be decreased.
 If you have installed a fly screen on the wall-box, the air vent may be obstructed.
Check by removing the fly screen.
 If the cover panel of the wall box is equipped with firm and slanted slats, the air
vent may be obstructed. Check by removing the cover panel.
 Install a cover panel with moveable slats, which do not obstruct the air vent.
 Check condition and cleanliness of the filters.
 Check if the air which is extracted by the hood is replaced to avoid negative
pressure.
 When you run your appliance in recirculating mode, check if the carbon filter has
been replaced on time (min. every 3 - 6 months).
If the appliance has a malfunction not noted on the schedule or if you have
checked all items on the schedule but the problem still exists, please
contact the aftersales service.
A
PPLIANCE VIBRATES
I
NSUFFICIENT EXTRACTING CAPACITY
A
PPLIANCE IS UNSTABLE
,
CHECK THE SCHEDULE BELOW
:
1. Fix motor properly.
2. Fix hood properly.
:
1. Lower position of hood.
2. Close the doors/windows.
:
1. Tighten the screws.
2. Fix the mounting
mounting plate properly.
/
OR YOU CAN HEAR
bracket /
:
