OWER CHIMNEY
5
U
PPER CHIMNEY
7
L
OUVRES
b. I
NSTALLATION OF THE CHIMNEY
The louvres (7) of the upper chimney (5) must face upwards and not be
covered by the lower chimney (4); s. fig. below.
4
L
OWER CHIMNEY
5
U
PPER CHIMNEY
7
L
OUVRES
(both sides)
/ R
ECIRCULATION MODE
(both sides)
