Endress+Hauser prowirl 77 Betriebsanleitung Seite 26

5 Kommunikation
26
Name E+H
Matrix
PB View_1 Object
TB View_1 Object
AI View_1 Object
Die zum Totalisator-Block gehörenden Parameter liegen in Slot 2, der Index ergibt sich
aus folgender Tabelle:
TOT Block Object
TOT Static Revision
TOT Tag Description
TOT Strategy
TOT Alert Key
TOT Target Mode
TOT Mode Block
TOT Alarm Summary
not used
TOT Out Total. V0H2
not used
TOT Units V1H1
not used
TOT Channel
TOT Reset Total. V4H1
TOT Operating Mode
not used
TOT Failsafe Mode
not used
TOT Polarity
not used
TOT Alarm Hysteresis
TOT HI HI Limit
TOT HI Limit
TOT HI HI Alarm
TOT HI Alarm
not used
TOT User Unit V1H4
TOT View_1 Object
* Parameter: O = Optional / Wahlparameter
M = Mandatory / Pflichtparameter
Index Read Write * Para-
meter
View_1 Objects of Blocks in Slot 1
201 X M
202 X M
203 X M
Totalizer Block (TOT)
0 X M
1 X M
2 X X M
3 X X M
4 X X M
5 X X M
6 X M
7 X M
8...9
10 X M
11
12 X X M
13
14 X X M
15 X X M
16 X X M
17
18 X X M
19
20 X X M
21
22 X X M
23 X X M
24 X X M
25 X M
26 X M
27...31
32 X X O
View_1 Object of Block in Slot 2
33 X M
Prowirl 77 PROFIBUS-PA
Data type Size Storage
bytes Class
Unsigned16,
DS-37,DS-42, 17 D
Octet String[4]
Unsigned16,
DS-37,DS-42 17 D
float
Unsigned16,
DS-37,DS-42, 18 D
DS-33
DS-32 20 C
Unsigned16 2 N
Octet String 32 S
Unsigned16 2 S
Unsigned8 1 S
Unsigned8 1 S
DS-37 3 N/Cst
DS-42 8 D
DS-33 5 D
Unsigned16 2 S
Unsigned16 2 S
Unsigned8 1 N
Unsigned8 1 S
Unsigned8 1 S
Unsigned8 1 S
float 4 S
float 4 S
float 4 S
DS-39 16 D
DS-39 16 D
float 4 S
Unsigned16,
DS-37,DS-42, 18 D
DS-33
Endress+Hauser
