General
3.2
Survey and construction
1
9
1.
Handle
2.
Lifting eye
3.
Battery-adapter cable with terminals
4. Vacuum pump
5.
Pressure gauge
6. Air filter
7.
Chain box
8. Suction plate
9. Wheel Set VPH-RS, allow to use the device by one person (optionally)
10. Stop for Wheel Set VPH-RS-AS, for large-size tiles (optionally)
3.3
Technical data
Type
Carying capacity/WLL [kg] valve at 500 mbar under-pressure
VPH-150
52710008/52710009
4
5
6
7
8
150
11 / 24
2
3
V7
10
Dead weight [kg]
16,5
