Spare parts

11 Spare parts
D10107-EN-R05
Table 2: Spare parts
Position Description
1 ... 15 LKF-Automotive with filter element 3 μm
LKF-Automotive with filter element 6 μm
LKF-Automotive with filter element 10 μm
2, 3, 4 LKF-Automotive, filter element 3 μm
LKF-Automotive, filter element 6 μm
LKF-Automotive, filter element 10 μm
5 , 8 , 9 LKF-Automotive, seal set, consisting of
2
1 × O-ring seal for container (material FVMQ)
5, 6, 8, 9, 10 LKF-Automotive, container with drain valve and seal set
7 LKF-Automotive, bayonet ring
11 Sealing plug PG7 with O-ring seal
12, 13, 14, 15 Sealing plug M14×1.5 with flat seal
×
O-ring seal for drain valve (material NBR)
REF
06 3802
06 3803
06 3800
06 3744
06 3745
06 3710
06 3746
06 3748
06 3664
06 1558
06 3681
