5. Maintenance
5.1
Maintenance schedule
Maintenance schedule
Oil level
Compressor oil
Air filter
Oil filter
Ait-Oil Separator
Drive belt
Heat exchanger
Bearings of electric
motor
Intake valve
Minimum pressure
valve
Safety valve
Beyond 6000 working hours, compressor maintenance consists in alternating M-2 and M-3
every 2000 hours of running time. Performance of daily, weekly, monthly and annual servic-
ing does not annul the need for maintenance in terms of operating hours.
5.2
Checking oil level
Fig. 5.2 Checking oil level
26
Daily
Monthly
Check/
Refill
Cleaning
Check
Cleaning
Yearly
M-1
500
Replace
Replace
Lubricate
Check
Check
Check
Check oil level on a daily basis. The oil lev-
el in the compressor should be checked
visually with the oil level glass (1) when
the compressor has stopped. The sur-
face of the oil must always be visible in
the sight glass. If no oil is visible in the
sight glass, the oil level is low and needs
to be topped up.
1
Interval in work hours
M-2
M-3
2000
4000
Replace
Replace
Replace
Replace
Replace
Replace
Replace
Version 1.0
