4.1.1 v-Log control panel
Fig. 4.1.1 v-Log control panel
Start compressor
Stop compressor
Back to the main menu
Accept value / manually switch between loaded and idle running
4.1.2 LCD indicator
COMPRAG Screw air compressor DV-Series
Power indicator (red): The indicator lights up when the control is switched on and
the power supply is connected.
Power indicator (green): The indicator lights up when the motor is running.
Alarm/error indicator (red). Alarm (warning): The indicator flashes and the ma-
chine continues to run. Error: The indicator is permanently lit, there is an accom-
panying acoustic signal and the machine switches off. The error message can be
acknowledged after the cause of the error has been resolved. In order to acknowl-
edge the error message, press and hold the 'back to main menu' button
Up or increase value
Down or reduce value
Save setting
.
