Installation instructions, only for experts
5. Connecting the electric heater to electrical net-
work
The heater is connected to the electrical network semi-stationarily with a H07RN-F
rubber cable or its equivalent. The use of PVC-insulated cable as a connecting
cable is prohibited due to thermal embrittlement. The electric installation may
only be administered by a qualified electrician adhering to current regulations.
The maximum distance of the junction box from the floor is 400 mm, measured
from the upper corner of the box. Make sure that the connecting cable will not
be exposed to thermal radiation or mechanical strain. If the rubber cable running
inside the wall of the sauna is above 1000 mm from the floor, it needs to endure
temperatures up to 170 degrees Celsius (for example SSJ).

6. Control unit

The control cable for electrical heating is brought directly into the junction box
of the heater, and from there to the terminal block of the heater. The power and
control unit should be installed in to a dry place between the heater and the
electrical center, either in the sauna or outside the sauna (depending on the
model). The thermostat is installed into the wall/or roof of the sauna according to
instructions and is connected with SSJ or similar silicone cable to the power unit.
See the more detailed instructions provided by the control unit's
manufacturer.
