3.3 Step 3: Installing the BRITA water dispenser
To install the BRITA water dispenser, fi rst make sure all the tools
you need are in front of you (see fi g. 5).
12 mm
Drill
(fi g. 5)
1. BRITA water dispenser
2. Base
(Work surface)
3. Gasket
4. Counter plate
5. Locking ring
6. Hexagon nut (7/16")
To start, fi nd a suitable place to set up your BRITA water dispenser
near your sink. We recommend installing it next to the sink on the
work surface (next to the main tap). Please make sure that there is
enough room for the P 1000 fi lter cartridge, the two hoses and the
electronic cartridge exchange indicator with display under the sink
or the drill hole.
!
Drill a hole (with a 12-mm bit) into the work surface where you
wish to set up the BRITA water dispenser.
Next, install the BRITA water dispenser (see illustration).
Then put the base (2) over the hole and fi x the BRITA water
dispenser (1) in place using the supplied counter plate (4), the
gasket (3), the locking ring (5) and the hexagon nut (6).
3.4 Step 4: Attaching the hoses
1.
2.
!
3.
4.
For wall mounting (optional), you need: two screws (e.g. 5 mm
5.
thread diameter) and, if required, two wall plugs suitable for your
type of wall.
6.
Please note that you will need the right drilling equipment
for your particular work surface or base. Make sure the
area under the dispenser is stable, especially if your work
surface is not made from wood. Please check the drilling
requirements for the material, use the appropriate drill and/
or consult a specialist.
We recommend that you fi rst arrange all parts you need in
front of you. Before installation, please ensure that you have
a free 3/8" or 1/2" cold water supply so that you can connect
the On Line Active Plus Water Filter Kit in addition to your
existing water dispenser. If you do not have a free 3/8" cold
water supply, please contact a professional. Recommended
tools for installation: one Allen key (5 mm) and one 12 mm
drill.
