7 Technical data of the On Line P 1000 cartridge
Operating pressure
Water intake temperature
operation
Ambient tem-
perature for
storage/transport
Filtration fl ow rate (acc. to JIS)
Nominal service fl ow (acc. to DIN
18879/NSF)
Capacity up to carbonate hardness
8.5 °dH at setting "+"
Capacity from carbonate hardness
8.5 to 17 °dH at setting "++"
Pressure loss
Empty fi lter cartridge volume
Weight (dry/wet)
Filter system
(fi lter head with fi lter
cartridge)
Dimensions
Filter cartridge
(Width/Depth/
Height)
Installed dimensions
(vertical installation
with wall mounting
bracket)
Operating position
Water inlet connection
Water outlet connection
2 bar to max. 8.6 bar
4°C to 30°C
4°C to 30°C
–20°C to 50°C
2.5 L/min
60 L/h
1000 L
500 L
0.2 bar at 60 L/h
1 L
1.0 kg/1.4 kg
117 mm/108 mm/265 mm
108 mm/108 mm/259 mm
137 mm/130 mm/265 mm
Horizontal and vertical
G3/8"
G3/8"
8 Troubleshooting
A No water fl ow
Cause: Water intake closed.
Troubleshooting: Open the water intake at the upstream shut-off
valve or by closing the locking handle (3) on the
fi lter head (2).
B No or low water fl ow in spite of open water intake
Cause: Mains pressure too low.
Troubleshooting: Check mains pressure. If the fault continues,
check the fi lter system and fi lter cartridge and
replace if necessary.
Cause: Filter head not mounted in direction of water
fl ow.
Troubleshooting: Dismantle fi lter head and install in direction of
water fl ow (chapter 3.4).
C Leak
Cause: Screwed connections not fi tted correctly.
Troubleshooting: Check mains pressure. Check all screwed
connections and mount as described in
chapter 3.4.
D Incorrect display or incorrect settings on the electronic
cartridge exchange indicator with display
Cause: Buttons pressed in wrong order or wrong
buttons pressed.
Troubleshooting: Press and hold the RESET button for 8 seconds.
