TECHNICAL DATA / INSTALLATION ECOPESI S
Doors of max. 9 m
ACG8193
n° 1 - AA40806
- ECOPESI S with limit switches without mounting plate L = 1 m
n° 1 - ACG8192
- Mounting plate L = 1 m
n° 1 - ACG2090
- Tubular shaft L = 3 m
n° 1 - ACG8158
- Pair of telescopic straight arms (or ACG8159 - Pair of telescopic curved arms)
n° 1 - ACG8164
- Accessories for the lateral transmission (central positioning)
Doors with area greater than 9 m
ACG8193
n° 1 - AA40806
- ECOPESI S with limit switches without mounting plate L = 1 m
n° 1 - AA40808
- ECOPESI S without mounting plate L = 1 m
n° 2 - ACG8192
- Mounting plate L = 1 m
n° 1 - ACG8156
- Pair of Telescopic straight arms (or ACG8157 - Pair of Telescopic curved arms)
T
ECHNICAL FEATURES
ECOPESI S is an irreversible gearmotor, used to operate counterweight-
balanced doors (Picture 1).
It is provided with an hydraulic reducing unit lubricated with synthetic grease,
with a motor protected by a thermal probe, with a manual release system
in case of power failure and with an (optional) longitudinal member, that
presents holes for a variable positioning of the motor during the installation.
Measurements in mm/in
2
ACG8191
ACG8192
ACG2090
2
ACG8191
ACG8192
ACG8156
2,36"
4,9"
7,7"
4,52"
AA40806
ACG8158
AA40806
ACG8157
TECHNICAL DATA
Max door surface
Max door width
Max. torque
Reduction unit
EEC power supply
Motor capacity
Power absorbed
Capacitor
Power supply
Motor capacity
Power absorbed
Capacitor
Normative cycles 230V
Normative cycles 120V
Daily cycles suggested
Service
Consecutive cycles guaranteed
Grease
Actuator weight
Noise
Operating temperature
1
Protection grade
18
18
18
18
ACG8159
AA40808
ECOPESI S
2
m
m
Nm
rpm
1,8 => 15s open/closed
230V ~ 50Hz
W
A
µF
120V ~ 60Hz
W
A
µF
n°
17 - 15s/2s
n°
70 - 8,5s/2s
n°
n°
BECHEM-RHUS 550
kg
db
°C
-10 ÷ +55°C
IP
ACG8164
9
3
300
295
1,4
12,5
256
2,55
40
30
60%
31
9
<70
30
