3. Connect the central telematics unit to the CCU of the
EN
Fig. 1:
ContiPressureCheck system in accordance with the following
explanations (see variant A or variant B).
CAUTION
Possible damage to property.
Connect a reverse polarity of the can data line of the CPC
system through the wiring harness N to the connection
plugs.
►
The white data cable of the CPC system must be
connected to the white cable of the wiring harness N.
The same applies to the brown data cables.
Variant A:
Connect the central telematics unit to a ContiPressureCheck system
with a display.
2
Sub-Harness N
(17341950000)
3
Variant A
In this case, only the wiring harness N contained in this kit is required
for the connection.
Connect the wiring harness N as shown in. "Fig. 1: Variant A"
‹
4
Sub-Harness B
(17340070000)
2
4
Sub-Harness C
(17340060000)
2
Sub-Harness A
(17340080000)
3
Sub-Harness D
(17340090000/
17340670000)
