CARDIOSTRONG EX90 Montage- Und Bedienungsanleitung Seite 39

D1 SENSOR WIRE 350mm
D2 SENSOR WIRE 350mm
D3 HANDLE PULSE WIRE
D4 HANDLE PULSE RING
Φ31.8*0.9T*19.5mm
D5 SPACER RING Φ32*30.4
D6 HANDLE PULSE
D7 UPPER HANDLE PULSE HOUSING
D8 LOWER HANDLE PULSE HOUSING
D9 HANDLE PULSE RING
Φ31.8*0.9T*30.5mm
D10 FOAM SPACER RING
Φ32*Φ25.8*10mm
1 M2 CLIP R32
1 M3 MOTOR
2 M4 SCREW
2 N1 BUSH Φ12.05*17*21.2mm
2 N2 CLIP (R40)
4 N3 BEARING 2203(MRB)
2 N4 SPACER RING (L)
2 N5 SPACER RING (R)
2 N6 SCREW
2
8
2
2
4
2
2
4
4
8
39
