CARDIOSTRONG EX90 Montage- Und Bedienungsanleitung Seite 38

A109 MOTOR SENSOR WIRE HOUSING
SCREW
B1 PEDAL SUPPORTING TUBE (L)
B2 PEDAL SUPPORTING TUBE (R)
B3 BEARING SLEEVE
B4 BEARING 6201 (TPX)
B5 LOWER PEDAL SUPPORTING TUBE 2
B7 PEDAL BRACKET (L)
B8 PEDAL BRACKET (R)
B9 PEDAL REST (L)
B10 PEDAL REST (R)
B11 FRONT COVER PEDAL (L)
B12 CUSHION PAD (L)
B13 PEDAL (L)
B14 SCREW 5/32"*5/8" (M14*15mm)
B15 SCREW M6*10mm
B16 PEDAL (R)
B17 CUSHION PAD (R)
B18 FRONT COVER PEDAL (R)
B19 UPPER CAP FOR PEDAL
SUPPORTING 20*60
B20 LOWER CAP FOR PEDAL
SUPPORTING 20*60
B21 SCREW 5/32"*1/2"
B22 MIDDLE PEDAL SUPPORTING
ROD
B23 NUT M8
B24 BUSH Φ8*(Φ12+Φ15)
B27 SCREW M8*40mm
B30 SCREW M12*133mm
B31 BUSH Φ15*Φ12.35*90mm
B32 BEARING 6003zz
C1 SIDE CONNECTING TUBE (L)
C2 SIDE CONNECTING TUBE (R)
D CONSOLE SUPPORTING TUBE
38
2 F1 CENTRAL SUPPORTING TUBE
1 F2 IRON BARCKET
1 F3 JOINT COVER (L)
4 F4 JOINT COVER (R)
14 F5 SCREW M10*16mm
F6 JOINT COVER SCREW
1 F7 ADJUSTED NUT
1 F8 ADJUSTED END Φ50
1 G CONSOLE
1 G1 SCREW M5*10
1 H WATER BOTTLE
1 J1 SCREW M8*16mm
1 J2 SCREW M8*60mm
6 J3 SCREW M12*73mm
8 J4 NUT M12
1 J5 SCREW M12*109mm
1 J7 BUSH
1 J8 SCREW M8*20mm
2 J9 WASHER M12*20
2 J10 SCREW
8 J11 SCREW
2 J12 END CAP
4 J13 PEDAL HOUSING (R)
8 J14 PEDAL HOUSING (L)
4 J15 SCREW
2 J16 PEDAL REINFORCEMENT STRIP
2 J17 SCREW
16 J18 CRANK HOUSING
1 J19 SCREW
1 J20 SIDE DECORATION HOUSING
SCREW
1 M1 BUSH
1
1
1
1
4
2
2
2
1
4
1
4
4
6
16
4
2
2
16
6
6
2
2
2
4
4
8
2
2
4
6
EX90
