A27 POWER CORD SOCKET
A28 SCREW M3*10
A29 SCREW M8*10
A30 TRANSPORTATION WHEEL
A31 SCREW M12*53
A32 PRESSING PIPE
A33 WASHER (Φ10*Φ23*2T)
A34 BEARING 6200(MRB)
A35 SCREW M10*30
A36 J SHAPE SCREW M6
A37 CONNECTION WIRE BETWEEN
SWITCH AC POWER AND POWER
CORD
A38 WASHER (M6*Φ16*2T)
A39 GROUND WIRE
A40 POWER CORD
A41 FLYWHEEL Φ327
A42 NUT 3/8"
A43 TENSION CABLE 400mm
A44 SCREW M5*10
A45 TURING PLATE
A46 CRANK
A47 BEARING NUT
A100 SCREW M4*20
A101 END CAP
A102 SMALL CHAIN COVER (L)
A103 MAIN CHAIN COVER (L)
A104 UPPER DECORATION HOUSING
A105 SMALL CHAIN COVER (R)
A106 MAIN CHAIN COVER (R)
A107 SCREW M4*12
A108 MOTOR SENSOR WIRE HOUSING
1 A75 BUSH Φ12.1*Φ16*10.5mm
2 A76 SCREW M4*38
2 A77 FLAT KEY 7*7*20mm
2 A80 FRONT PEDAL SUPPORTING
TUBE
4 A81 WASHER Φ10*Φ27*2T
1 A82 SCREW M10*40mm
2 A83 NUT
2 A84 BRAKE
1 A85 SPRING
1 A87 AXLE FOR MOTOR PUSH ROD
1 A88 NUT
1 A89 NYLON SLEEVE
1 A90 PUSH ROD BRACKET (FRONT)
1 A91 END CAP
1 A93 PUSH ROD BRACKET (REAR)
2 A94 SCREW M8*20
1 A95 SCREW 5/32"*3/4" (M4*19mm)
4 A96 NUT M6
2 A97 SIDE DECORATION HOUSING
SET (L)
2 A98 SIDE DECORATION HOUSING
SET (R)
1 A99 FRONT SIDE DECORATION
COVER
10 D11 END CAP
4 D12 SPONG HDR Φ23*3T*150
1 D13 SPONG HDR Φ23*3T*34
1 D14 SCREW M4*4mm
1 E1 HANDLE BAR (L)
1 E2 HANDLE BAR (R)
1 E3 END CAP 1 1/4"
8 E4 SPONG HDR Φ30*3T*615
2 E5 CONNECTION SLICE 38 (4T)
4
4
2
2
2
2
4
1
1
2
2
8
2
1
2
8
12
2
2
2
2
2
2
2
2
1
1
2
2
4
