Please note:
Only close the Click & Lock
closures by pushing against the latch with
your thumbs while simultaneously crea-
ting counter pressure with your fingers
(fig. 42). This will ensure that neither the
leg nor the hip of the patient are subjected
to any possibly harmful pressure.
42
12.
It may be necessary to open the central
buckle of the pelvic brace again in order
to be able to easily push the latches of
the Click & Lock closures into position.
Afterwards, the central buckle can be
closed again.
13.
Please consider the following when
closing the Click & Lock closure on
the panel: For all length settings
(minimum, maximum and in between)
each of the two pins must lock into
one of the holes in the bar. Only then
the Click & Lock closures will sit flush
against the orthosis. In case the Click
& Lock closure can later not be locked
completely, push or pull the bar up
or down a little, until both pins have
audibly locked into the next hole.
DynaCox® evolution
14.
After pushing the latches flush against
the orthosis, any unintended opening
of the DynaCox evolution will not be
possible anymore. To open the Click &
Lock closures, insert an Allen key into
the opening on the back of the closure
(fig. 43), and push the latch open (fig.
44). This opening can be found on the
closures on the femoral panel and on
the pelvic panels.
43
44
