20.0 DIMENSIONS / SPECIFICATIONS
Fig. 28
.
30mm
.
1 3 / "
16
145mm
3 / "
5 45mm
4
1 3 / "
4
150mm
7 / "
5
8
THE RANGE OF APPLICATION
Model No. Max Lifting Force
ATM-3
27 kN

23.0 PARTS LIST ATM-3

Fig. 29
16
2 14
12
3
10
4
11
32
5
6
33
8
9
31
15
30
Repair Kit 1: (Thrust Bearing Set)
✱
Part No. EN403601
Contains items 4, 5, 6, 8 and 9
Repair Kit 2: (Roller Bearing Set)
■
Part No. EN403701
Contains items 13,14,15 and 16
Repair Kit 3: (Tool Assembly Set)
●
Part No. EN403801
Contains items 9, 18, 19, 20, 21, 31
and 33
Repair Kit 4: (Ratchet Service Set)
▲
Part No. EN403901
Contains items 22, 23, 25, 26, 27,28,
29 and 32
480mm
7
18 / "
8
380mm
15"
230mm
.
9 1 "
/
16
.
. .
340mm
.
13
.
.
Weight
3 ton 24 lbs
11kg
17
15
18
13
19
19
. .
19
19
12 22
23
13
29
14
24
28
25
16
27
26
21.0 DISMANTLING THE ATM-3
• Once alignment is achieved, all work on the joint
finished, and bolt-up completed (apart from the
bolt hole in which the ATM-3 is housed), the tool
can be dismantled by reversing steps Fig. 14-16
in paragraph 12.0.
• Care should be taken not to drop any of the
component parts when removing them from the
aligned joint. This action will prevent injuries to
either the operator's lower limbs, or to passers-
3 / "
8
by.
22.0 STORAGE
• The ATM-3 should be stored in a cool dry place.
• Machined surfaces are to be smeared with
grease.
No. Description
2. Torque Wrench with
22 mm socket
3. Screw Bolt
✱ 4. Spring Clip
5. Swivel
✱
6. Thrust Bearing Kit
✱
8. Friction Pad
✱
20
●✱ 9. Retaining Screw
. .
10. Wing
11. Body Plates / Frame
20
21
12. Roller Pin
■ 13. Spiral Clip
14. Inner Roller
■
15. Needle Bearing
■
16. Outer Roller
■
17. Handle
18. Retaining Screw
●
19. Retaining Screws
●
20. Wing Retaining Clip
●
● 21. Screw
22. Spring
▲
23. Set Screw
▲
24. Drop Leg
▲ 25. Drop Leg Pad
26. Retaining Screw
▲
27. Retaining Screw
▲
28. Release Knob
▲
▲ 29. Drop Leg Lock
30. Lift Hook
31. Pull Pin
●
32. Roll Pin
▲
● 33. Spring Ball
11
Qty. Part No.
1 TW22**
1 EN400301
1 ✱
1
✱
1 kit
✱
1
✱
1 ●✱
1 EN401001
1 set EN401101
2 EN401201
2 ■
2
■
2
■
2
■
1 EN401701
1
●
7
●
1 kit
●
1 ●
1
▲
1
▲
1 EN402401
1 ▲
2
▲
2
▲
2
▲
1 ▲
1 EN403001
1
●
1
▲
1 ●
