Sachs PSM69-48-002-01-22 Einbau- Und Montageanleitung Seite 39

Performance-Gewindefahrwerke
Performance Coilover Kits
Kit-Nr.: PSM69-48-002-01-22

Never use impact wrenches or guns to install or remove shock absorber piston hardware.

Never disassemble or cut open shock absorbers and/or shock absorber inserts. They contain oil
under pressure. Danger of explosion!

Before driving on public highways, carry out the work steps after installation.

The suspension regulation (when available) needs to be disabled through an authorized dealer.

Please take care in any case that fittings (for example fittings of shock absorber housings or
fittings of the lower control arm in the housing of the wheel bearing) are free of dust and oil. (see
manufacturer guideline)
Instructions for Use:

When adjusting the vehicle height, make sure that the threads are clean and free of debris. After
initial cleaning, move the perch by 10 mm (0.4 Inches) downwards, and then clean the area that
you desire to adjust the perch (up or down).

During height adjustments on separate shock and spring systems, remove the perch from the
vehicle to adjust the height.

After adjusting the vehicle height, repeat steps.

In the area of the piston rod and the sealing package of the new and used damper might be oil
and grease collected.

This could either be caused by using a special black grease during assembling the washer or due
to accumulation of streak oil. Furthermore oil is used during assembling the cartridge and rod
guide. There is no reason of worrying about and damage, as in this area also dust and dirt used
to be collected.
Mounting Specifications:

The suspension components may only be installed by trained technical personnel using the
proper tools.

We recommend the use of a vehicle hoist or lift when installing the suspension. If a lift is not
available and jacking equipment is used, make sure that the vehicle is secured with commercial
wheel blocks and jack stands to ensure safety.

Caution: If the vehicle is equipped with ride height sensors, they should be removed before
removal of struts or dampers, otherwise damage may occur.

The struts should be removed as specified by manufacturer's instructions.

Install the suspension components in the vehicle as specified by the vehicle manufacturers in
their document.

Manufacturer recommended tools for removal of the original struts, or a suitable spring
compressor, must be used in order to remove most factory mounted suspension systems.
Hinweis Nr. 1798000811
Instruction No. E694800201
Erstellt am: 26.03.2019
Date:
Seite 39 von 42
Page 39 of 42
