4.4

RECORDING A FINGER WITH THE SENSOR (SEE FIGURE 4)

It is important that the user draw his/her finger correctly across the sensor.
Note: The best results are achieved by using the middle finger while spreading the
pointer and ring fingers away from the middle finger.
Place the entire surface of the desired finger after the last joint onto the sensor.
The larger the surface area of the finger, the higher the probability will be that the finger
is recognised by the device the next time it is placed on the sensor.
The sensor is located in the middle of the slide next to the indicators illuminated in green
(see figure 2 on page 3). Apply just the right pressure (not too hard and not too soft)
and drag the finger across the sensor at medium speed. Manual workers should be aware
that their finger lines are likely to wear off, which means that a right-handed worker
should record fingers on his/her left hand and vice versa.
ATTENTION:
Please swipe the largest possible finger surface, starting from the first finger
joint and applying gentle pressure. The larger the scanned finger surface, the
easier it will be for the finger to be recognised.
4.5

HOW TO ENROL A FINGER

1. ENTERING THE SECURITY CODE
1.1. Press the OK-key in the control panel.
1.2. Enter the first digit of the security code using < and > (standard setting is 9)
1.3. Press the OK-key.
1.4. Enter the second digit of the security code using < and > (standard setting is 9)
1.5. Press the OK-key.
1.6. In the display "Eu" (enrol user) is visible.
2. SETTING ACCESS AUTHORITIES
2.1. If "Eu" is visible in the display of the control panel, press the OK-key.
2.2. Setting user number: The display shows "1". If the user ID is already taken, a
red dot appears in the lower right hand corner of the display. Example: "1."
Select a user ID by using the < and > keys.
2.3. Press the OK-key.
2.4. Setting finger number: The display shows "F1". F1 stands for finger 1. Start
counting your fingers from the little finger of the left hand. The little finger of
your right hand would then be number 10 (setting "F0" in the display) e.g. "F7"
would be the index finger of your right hand. If a finger ID is already in use a red
dot appears in the lower right hand corner of the display.
2.5. Press the OK-key.
22
