English
1

SCOPE OF DELIVERY (SEE FIGURE 1)

The standard scope of delivery for ekey
integra contain the items according to the table on page 3.
®
ekey TOCAhome pc integra can be connected to a personal computer via the supplied
®
ekey Converter USB.
Optionally, a number of decor elements are offered in different designs.
2

DEVICE OVERVIEW (SEE FIGURE 2)

Your product is equipped with a finger scanner. This scanner reads special
characteristics of your fingerprint lines and uses them for subsequent recognition.
Each of your fingers is characterized by recognizably different marks and is completely
unique.
®
ekey TOCAhome integra option
This option is equipped with one relay.
®
ekey TOCAhome 3 integra option
This option is equipped with three relays that can be assigned to different fingers.This
option allows you, for example, to control a building door, a garage door and an alarm
system.
®
ekey TOCAhome pc integra option
As with the ekey
can also connect the device to a personal computer by means of a USB interface.
3

INSTALLATION

3.1

ELECTRICAL CONNECTION (SEE FIGURE 4)

The control panel has to be connected to the electricity. The supply voltage for the units
is 9VAC (alternating voltage) or 12VDC. For this purpose please use the "9VAC-in" spring
clips and use either the provided energy supply or a sufficiently powerful power supply.
Please pay attention not to exceed the 9VAC or 12VDC. The use of a bell transformer
will destroy the device. This will result in a loss of warranty.
The control panel and scanner must be connected to each other with the provided
preassembled wire. For this please connect the RJ45 plug to the scanner. The second
ending can be shortened to the desired length. Shield the cable approximately at
100mm, isolate the 4 wires and connect them according the installation scheme (figure
4) to the spring clips 3 and 4.
There is 1 relay (3 relays for the ekey(R) TOCAhome 3 integra and ekey(R) TOCAhome
pc integra options) available for control of external devices. The programming menu is
®
TOCAhome 3 option, this option is equipped with three relays. You
®
TOCAhome integra and ekey
®
TOCAhome 3
19
