Motherboard Layout
USB 3.0
T: USB0
B: USB1
USB 3.0
T: USB2
B: USB3
USB 3.0
T: USB4
Top:
RJ-45
B: USB5
51
USB 2.0
T: USB0
B: USB1
USB 2.0
T: USB2
B: USB3
MOS_FAN1
CHA_FAN4
50
49
X
fast USB
48
X
Fast RAM
47
X
Fast LAN
46
45
RoHS
44
AUDIO
CODEC
43
42
HDMI_SPDIF1
1
HD_AUDIO1
COM1
1
41
40
1
ATX 12V Power Connector (ATX12V2)
2
ATX 12V Power Connector (ATX12V1)
3
1155-Pin CPU Socket
4
CPU Fan Connector (CPU_FAN1)
5
CPU Fan Connector (CPU_FAN2)
6
2 x 240-pin DDR3 DIMM Slots
(DDR3_A1, DDR3_B1, Black)
7
2 x 240-pin DDR3 DIMM Slots
(DDR3_A2, DDR3_B2, Yellow)
8
Dr. Debug
9
PCIe ON/OFF Switch
10
Rapid OC Button (-)
11
Rapid OC Button (+)
12
Post Status Checker (PSC)
TM
13
V-Probe
(VOL_CON1, VOL_CON2)
14
ATX Power Connector (ATXPWR1)
15
USB 3.0 Header (USB3_6_7, Black)
16
Power Fan Connector (PWR_FAN1)
17
Chassis Fan Connector (CHA_FAN3)
18
SATA2 Connectors (SATA2_4_5, Black)
19
SATA2 Connectors (SATA2_2_3, Black)
20
SATA3 Connectors (SATA3_0_1, Yellow)
21
SATA3 Connectors (SATA3_M0_M1, Yellow)
22
SATA3 Connectors (SATA3_M2_M3, Yellow)
23
Chassis Speaker Header (SPEAKER1, Black)
24
Power LED Header (PLED1, Black)
25
System Panel Header (PANEL1, Black)
2
ASRock Z77 OC Formula Motherboard
manuals search engine
1
2
3
4
5
6
7
8
26.7cm (10.5 in)
ATX12V1
CPU_FAN1
ATX12V2
Dr.
CPU_FAN2
Debug
-
Front
USB 3.0
PCIE1
PCI Express 3.0
PCIE2
Z77 OC Formula
Intel
PCIE3
CMOS
Battery
1
CLRCMOS1
Z77
PCIE4
SPEAKER1
PCIE5
BIOS_SEL1
SLI/XFIRE_PWR1
1
CHA_FAN1
USB8_9
USB6_7
IR1
CHA_FAN2
USB4_5
64Mb
64Mb
Reset
Power
BIOS
BIOS
1
1
1
1
1
CIR1
39
38
37
36
35
34
33
32
31
30
29
28
27
26
26
Intel Z77 Chipset
27
Power Switch (PWRBTN)
28
Reset Switch (RSTBTN)
29
64Mb SPI Flash Memory (Backup BIOS)
30
64Mb SPI Flash Memory (Main BIOS)
31
USB 2.0 Header (USB4_5, Black)
32
BIOS Selection Jumper (BIOS_SEL1)
33
Chassis Fan Connector (CHA_FAN2)
34
USB 2.0 Header (USB6_7, Black)
35
USB 2.0 Header (USB8_9, Black)
36
Consumer Infrared Module Header (CIR1, Gray)
37
Chassis Fan Connector (CHA_FAN1)
38
Infrared Module Header (IR1)
39
SLI / XFIRE Power Connector (SLI/XFIRE_PWR1)
40
COM Port Header (COM1)
41
Front Panel Audio Header (HD_AUDIO1, Black)
42
HDMI_SPDIF Header (HDMI_SPDIF1, Black)
43
PCI Express 2.0 x16 Slot (PCIE5, Yellow)
44
PCI Express 3.0 x16 Slot (PCIE4, Yellow)
45
PCI Express 2.0 x1 Slot (PCIE3, Black)
46
Clear CMOS Jumper (CLRCMOS1)
47
PCI Express 3.0 x16 Slot (PCIE2, Black)
48
PCI Express 2.0 x1 Slot (PCIE1, Black)
49
Chassis Fan Connector (CHA_FAN4)
50
MOS Fan Connector (MOS_FAN1)
51
Twin-Power Cooling
9
10
+
11
12
13
14
15
USB3_6_7
16
PWR_FAN1
17
CHA_FAN3
18
19
20
21
22
23
1
24
PLED1
1
PANEL1
PLED PWRBTN
25
1
HDLED RESET
