OPERATION:

COLOUR TEMPERATURE PRESETS
Press the MODE button repeatedly until "CTxx" appears in the display.
Now the preset with the desired colour temperature can be selected in 17
fine increments using the UP and DOWN buttons, whereby Preset 01 is
equivalent to a colour temperature of 3200K and Preset 17 is equivalent to
cold white at 6500K.
By pressing ENTER again, you can add a stroboscope effect (FSxx) to the
selected preset. The speed of the stroboscope (FS01 - FS99) is set using
the UP and DOWN buttons. Setting FS00 deactivates the stroboscope effect.
Pressing the ENTER button again returns the light to preset selection mode.
MANUAL ADJUSTMENT OF THE COLD WHITE / WARM WHITE MIxING
RATIO
Press the MODE button repeatedly until "Cuxx" (cold white) appears in the
display. Now, using the UP and DOWN buttons, you can set the intensity of
the cold white LEDs from 00 to 99. To set the intensity of the warm white
LEDs, press ENTER. Now the display will read "uu00" (warm white). Next,
use UP and DOWN to select the desired value (uu00 - uu99).
By pressing ENTER again, you can now add a stroboscope effect (FSxx).
The speed of the stroboscope (FS01 - FS99) is set using the UP and DOWN
buttons. Setting FS00 deactivates the stroboscope effect.
SELECTING THE DMx START ADDRESS
Press the MODE button repeatedly until "A" and 3 additional characters
appear in the display. Now you can use the UP and DOWN buttons to select
the desired DMX start address (A001 - A512).
SELECTING DMx MODE
Press the MODE button repeatedly until the DMX start address appears in
the display. Press ENTER and use the UP and DOWN buttons to select the
desired DMX mode (02CH, 05CH, 06CH).
