OPERATION:
SELECTING THE DIMMER CURVE
Press the MODE button repeatedly until the DMX start address appears in
the display. Now press ENTER twice and use the UP and DOWN buttons to
select the desired dimmer curve (01CU - 08CU).
Dimmer curves 01CU - 04CU: The light behaves in a manner similar to
that of a halogen lamp with gentle changes in brightness.
Dimmer curves 05CU - 08CU: The light reacts abruptly to changes in the
DMX value.
Dimmer curve 01CU / 05CU linear: The light intensity increases linearly
with the DMX value.
Dimmer curve 02CU / 06CU exponential: Adjustment of the light
intensity is finer in the lower DMX value range and coarser in the upper DMX
value range.
Dimmer curve 03CU / 07CU logarithmic: Adjustment of the light intensi-
ty is coarser in the lower DMX value range and finer in the upper DMX value
range.
Dimmer curve 04CU / 08CU S-curve: Adjustment of the light intensity is
fine in the lower and upper DMX value ranges and coarse in the middle DMX
value range.
Dimmer curves
linear exponential logarithmic S-curve
DMX value DMX value DMX value DMX value
SLAVE MODE
Press the MODE button repeatedly until "SLAV" appears in the display.
Connect the slave and master unit of the same type with a DMX cable
(master unit DMX OUT - slave unit DMX IN). Now the slave unit follows the
master unit.
Unless one of the 4 buttons is pressed, the LED display switches off
automatically after approx. 40 seconds. As soon as one of the four buttons is
pressed, the display switches on again.
