Operating Instructions
QJ 600-E
REGULATORY SIGN
Symbol Meaning
Each operator must have read and understood the operating
instructions (and all safety instructions).
3.2.1

Function Control

● Before using the device check the functions and the working condition.
● Maintenance and lubrication are only permitted when device is shut down!
● Do not use the device, until all faults which can cause safety hazards are removed.
● If there are any cracks, splits or damaged parts on any parts of the device, immediately stop using it.
● The operating instructions must be available at the workplace every time.
● Do not remove the data-plates of the machine.
● Unrecognisable information signs must be replaced.
3.1

Safety at work

● The use of the vacuum lifting device is only permitted in proximity to the ground. Do not swing it over
peoples heads.
● The manual guiding of is only allowed for devices with handles.
● The operator is not allowed to leave the control unit as long as the vacuum lifting device loaded with
load (stone slab). The load must always be in the range of vision of the operator.
● Always keep an eye on the vacuum gauge. Never lift loads when the vacuum is below the required
under pressure (mbar). If the pointer of the pressure gauge moves into the red danger zone, lower
the load immediately! Danger! Load could fall down!
● While using the vacuum lifting device is the stay of persons in the working area forbidden. Except it is
indispensable. Caused of the way of using the vacuum lifting device , e.g. if the device must be
leaded by hand.
● While using the vacuum lifting device be sure that there are no persons in the working area. Danger
to Life!!
● The device must never be subjected to a force acting in a lateral direction due to diagonal pulling.
● Do not lift any components off-centre, because that could fall down. Danger of tilting!
● Release the load only when it is completely safely resting on the surface. Keep fingers away from
the load when you release it as they can be crushed!
● The capacity and the nominal width the vacuum lifting device are not allowed to cross over.
● Do not use the vacuum lifting device to jerk seized set down load.
● Avoid quick or jerky movements with the vacuum lifting device. E.g. caused through driving fast over
uneven grounds/site is forbidden.
6 / 25
Safety
Because the gripping good could fall down.
Order-No.: Size::
2904.0366 30 mm
2904.0365 50 mm
GB
