14
STEUERBEFEHLE
D Befehlstabelle (Fortsetzung)
Befehl Sub-Befehl
Daten
1A
05 0177
00/01
0178
00 to 02
0179
00/01
0180
00/01
0181
00 to 02
0182
00 to 20
0183
00 to 03
0184
00 to 09
0185
0000 to
0255
0186
00/01
0187
00/01
0188
00/01
0189
00/01
0190
00
01
02
03
04
05
0191
00 to 06 Send/read APF AF level.
0192
0000 to
0255
0193
00 to 05 Send/read the TX Delay setting (HF)
0194
00 to 05 Send/read the TX Delay setting (50M)
0195
00, 01
0196
0000 to
0223
0197
0198
00, 01
0199 000001 to
065535
0200 000001 to
065535
0201 000001 to
065535
Beschreibung
Send/read antenna temporary memory
set (00=OFF, 01=ON)
Send/read antenna selection
(00=OFF, 01=Manual, 02=Auto)
Send/read usage for ANT2
(00=OFF, 01=TX/RX)
Send/read usage for ANT3
(00=OFF, 01=TX/RX)
Send/read usage for ANT4
(00=OFF, 01=TX/RX, 02= RX)
Send/read VOX delay
(00=0.0 sec. to 20=2.0 sec.)
Send/read VOX voice delay
(00=OFF, 01=Short, 02=Mid., 03=Long)
Send/read NB depth (00=1 to 09=10)
Send/read NB width
(0000=0 to 0255=255)
Send/read external keypad set
for RTTY memory (00=OFF, 01=ON)
Send/read external keypad set
for PSK memory (00=OFF, 01=ON)
Voice memory transmission set for
[F1]– [F4] on the keyboard (00=OFF,
01=ON)
Memory keyer transmission set for
[F1]– [F4] on the keyboard (00=OFF,
01=ON)
Send/read time-out timer OFF
Send/read 3 min. time-out timer
Send/read 5 min. time-out timer
Send/read 10 min. time-out timer
Send/read 20 min. time-out timer
Send/read 30 min. time-out timer
(00=0 dB to 06=+6dB)
Send/read LAN MOD output level
(0000=0% to 0255=100%)
( 00=OFF, 01=10 ms, 02=15 ms,
03=20 ms, 04=25 ms, 05=30 ms)
( 00=OFF, 01=10 ms, 02=15 ms,
03=20 ms, 04=25 ms, 05=30 ms)
Send/read the Shutdown function.
( 00=Shutdown, 01=Standby/Shut-
down)
Send/read the transceive CI-V
Address for LAN to REMOTE in
hexadecimal code.
(0000=00h to 0223=DFh)
Send/read the default gateway set
( 0000000000000001=0.0.0.1 to 0255
025502550254=255.255.255.254, or
FF=Blank)
Send/read the remote control capa-
bility. (00=OFF, 01=ON)
Send/read the control port setting by
accessing from internet.
(000001=1 to 065535=65535)
Send/read the serial port setting by
accessing from internet.
(000001=1 to 065535=65535)
Send/read the audio port setting by
accessing from internet.
(000001=1 to 065535=65535)
Befehl Sub-Befehl
Daten
1A
05 0202
00, 01
0203
S. 14-14
0204
00 to 04 Send/read the maximum AF sample
0205
00 to 02 Send/read the AF codecs for remote
0206
00, 01
0207
00 to 04 Send/read the maximum modulation
0208
00 to 02 Send/read the modulation codecs for
0209
00, 01
0210
S. 14-11
0211
00, 01
0212
00 to 07 Send/read the peak color level for
0213
00, 01
0214
S. 14-11
0215
00, 01
0216
S. 14-11
0217
00, 01
0218
01 to 15 Send/read the repeat interval to
0219
00, 01
0220
00, 01
0221
00, 01
0222
00, 01
0223
00 to 03 Send/read QSO PLAY Skip time.
Beschreibung
Send/read the internet access line
setting.
( 00=FTTH (Fiber To The Home),
01=ADSL/CATV)
Send/read Network radio name
(up to 16-character)
rates for remote stations.
( 00=8 kHz, 01=12 kHz, 02=16 kHz,
03=24 kHz, 04=48 kHz)
stations.
( 00=LPCM 8bit,
01=LPCM 8bit, u-law 8bit,
02=LPCM 8bit, u-law 8bit, LPCM 16bit)
Send/read the network TX audio set-
ting for remote stations.
(00=OFF, 01=ON)
sample rates for remote stations.
( 00=8 kHz, 01=12 kHz, 02=16 kHz,
03=24 kHz, 04=48 kHz)
remote stations.
( 00=LPCM 8bit,
01=LPCM 8bit, u-law 8bit,
02=LPCM 8bit, u-law 8bit, LPCM 16bit)
Send/read the waveform outline indi-
cation on the spectrum scope.
(00=Fill, 01=Fill+Line)
Send/read the waveform outline
color for receiving signal.
Send/read the waterfall display on the
Spectrum scope. (00=OFF, 01=ON)
displaying the waterfall.
00=Grid 1, 01=Grid 2, 02=Grid 3,
03=Grid 4, 04=Grid 5, 05=Grid 6,
06=Grid 7, 07=Grid 8
Send/read waveform type on the
Audio FFT scope.
(00=Fill, 01=Line)
Send/read waveform color for Audio
FFT scope.
Send/read the waterfall display on the
Audio FFT scope. (00=OFF, 01=ON)
Send/read waveform color for Audio
Oscilloscope scope.
Send/read the voice 1st menu.
(00=VOICE-Root, 01=VOICE-PLAY)
transmit the recorded voice audio.
(01=1 sec. to 15=15 sec.)
Send/read the recording mode.
(00=TX&RX, 01=RX Only)
Send/read the squelch status for the
RX voice audio recording
(00=Always, 01=Squelch Auto)
Send/read the QSO audio record file
Split function setting.
(00=OFF, 01=ON)
Send/read the PTT Automatic Recor-
ding function setting.
(00=OFF, 01=ON)
( 00=3 sec., 01=5 sec., 02=10 sec.,
03=30 sec.)
