14
STEUERBEFEHLE
1
D Befehlstabelle (Fortsetzung)
Befehl Sub-Befehl
Daten
1A
05 0053
00 to 02
0054
00/01
0055
00/01
0056
00/01
0057
S. 14-11
0058
20000101
to
20991231
0059
0000 to
2359
0060
00/01
0061
S. 14-10
0062
S. 14-11
0063
00/01
0064
00/01
0065
00
01
02
03
0066
0050 to
0200
0067
00/01
0068
S. 14-11
0069
S. 14-11
0070
00/01
0071
00/01
0072
00/01
0073
00/01
0074
S. 14-11
0075
00 to 02
0076
00 to 02
0077
00/01
0078
00 to 02
0079
00/01
0080
00/01
0081
00/01
0082
00/01
0083
00/01
Beschreibung
Set/read screen saver type
(00=Bound, 01=Rotation, 02=Twist)
Send/read output signal setting for
external display (00=OFF, 01=ON)
Send/read synchronous pulse
level setting (00=L, 01=H)
Send/read opening message display
(00=OFF, 01=ON)
Send/read opening message contents
Send/read date
(20000101=1st Jan. 2000 bis
20991231=31st Dec. 2099)
Send/read time
(0000=00:00 to 2359=23:59)
Send/read CLOCK2 function
(00=OFF, 01=ON)
Send/read offset time for CLOCK2
(240001=–24:00 to 240000=+24:00)
Send/read CLOCK2 name
(up to 3-character)
Send/read calibration marker
(00=OFF, 01=ON)
Send/read confirmation beep
(00=OFF, 01=ON)
Band edge beep OFF
Band edge beep ON (Beep sounds
with a default amateur band)
Band edge beep with user setting ON
Band edge beep with user setting/TX
limit ON
Send/read beep audio frequency
(0050=500 Hz to 0200=2000 Hz)
Send/read quick split set
(00=OFF, 01=ON)
Send/read FM split offset –9.999 to
+9.999 MHz for HF
Send/read FM split offset –9.999 to
+9.999 MHz for 50 MHz
Send/read split lock set
(00=OFF, 01=ON)
Send/read tuner auto start set
(00=OFF, 01=ON)
Send/read PTT tune set
(00=OFF, 01=ON)
Send/read transverter set
(00=Auto, 01=ON)
Send/read transverter offset
Send/read RTTY mark frequency
( 00=1275 Hz, 01=1615 Hz,
02=2125 Hz)
Send/read RTTY shift width
(00=170 Hz, 01=200 Hz, 02=425 Hz)
Send/read RTTY keying polarity
(00=Normal, 01=Reverse)
Send/read PSK bisne frequency
( 00=1000 Hz, 01=1500 Hz,
02=2000 Hz)
Send/read speech language
(00=English, 01=Japanese)
Send/read speech speed
(00=Slow, 01=Fast)
Send/read S-level speech
(00=OFF, 01=ON)
Send/read speech with a mode switch
operation (00=OFF, 01=ON)
Send/read memo pad numbers
(00=5 ch, 01=10 ch)
Befehl Sub-Befehl
Daten
1A
05 0084
00 to 02
0085
00/01
0086
00/01
0087
00 to 02
0088
00 to 02
0089
00/01
0090
00/01
0091
00/01
0092
00/01
0093
00/01
0094
00/01
0095
00/01
0096
00/01
0097
00 to 04
0098
00 to 10
0099
0010 to
0100
0100
00 to 31
0101
–
0102
01 to 30
0103
00/01
0104
00/01
0105
00 to 02
0106
S. 14-11
0107
S. 14-11
0108
00 to 02
0109
00 to 02
0110
00 to 02
0111
00 to 02
0112
00 to 02
Beschreibung
Send/read main dial auto TS
(00=OFF, 01=Low, 02=High)
Send/read mic. up/down speed
(00=Low, 01=High)
Send/read quick RIT/
TX clear
:
function (00=OFF, 01=ON)
Send/read SSB notch operation
(00=Auto, 01=Manual, 02=Auto/
Manual)
Send/read AM notch operation
(00=Auto, 01=Manual, 02=Auto/Manual)
Send/read DIGI-SEL control function
(00=DIGI-SEL, 01=APF)
Send/read SSB/CW synchronous
tuning function (00=OFF, 01=ON)
Send/read CW normal side set
(00=LSB, 01=USB)
Set/read APF type
(00=SHARP, 01=SOFT)
Send/read external keypad set
for voice memory (00=OFF, 01=ON)
Send/read external keypad set
for keyer memory (00=OFF, 01=ON)
Send/read CI-V transceive set
(00=OFF, 01=ON)
Send/read RS-232C function
(00=CI-V, 01=Decode)
Send/read RS-232C decode
Baud rate (00=300, 01=1200, 02=4800,
03=9600, 04=19200)
Send/read keyboard type
(00=English, 01=Japanese,
02=United Kingdom, 03=French,
04=French (Canadian),
05=German, 06=Portuguese,
07=Portuguese (Brazilian),
08=Spanish, 09=Spanish (Latin
American), 10=Italian)
Send/read keyboard repeat delay
( 0010=100 msec., 0100=1000 msec.;
50 msec. steps)
Send/read keyboard repeat rate
(00=2.0 cps to 31=30.0 cps)
Send/read IP address set
(0000000000000001=0.0.0.1 bis
0255025502550254=255.255.255.254)
Send/read subnet mask
(01=128.0.0.0 to 30=255.255.255.252)
Send/read scope display during
TX (00=OFF, 01=ON)
Send/read scope max. hold
(00=OFF, 01=ON)
Send/read scope center frequency
set (00=Filter center, 01=Carrier
point center, 02=Carrier point center
(Abs. Freq.))
Send/read waveform color for receiving
signal
Send/read waveform color for max. hold
Send/read scope sweep speed for ±2.5
kHz span (00=Slow, 01=Mid., 02=Fast)
Send/read scope sweep speed for ±5
kHz span (00=Slow, 01=Mid., 02=Fast)
Send/read scope sweep speed for ±10
kHz span (00=Slow, 01=Mid., 02=Fast)
Send/read scope sweep speed for ±25
kHz span (00=Slow, 01=Mid., 02=Fast)
Send/read scope sweep speed for ±50
kHz span (00=Slow, 01=Mid., 02=Fast)
