14
STEUERBEFEHLE
1
D Befehlstabelle (Fortsetzung)
Befehl Sub-Befehl
Daten
14
11
0000 to
0255
12
0000 to
0255
13
0000 to
0255
14
0000 to
0255
15
0000 to
0255
16
0000 to
0255
17
0000 to
0255
18
0000 to
0255
19
0000 to
0255
15
01
00
01
02
0000 to
0255
11
0000 to
0255
12
0000 to
0255
13
0000 to
0255
14
0000 to
0255
15
0000 to
0255
16
0000 to
0255
16
02
00
01
02
12
00
01
02
03
22
00
01
32
00
01
02
03
40
00
01
41
00
01
42
00
01
43
00
01
Beschreibung
Send/read [AGC] level
(0000=max. CCW to 0255=max. CW)
Send/read NB level
(0000=0%, 0255=100%)
Send/read [DIGI-SEL] position
(0000=max. CCW to 0255=max. CW)
Send/read DRIVE gain
(0000=0%, 0255=100%)
Send/read Monitor gain
(0000=0%, 0255=100%)
Send/read VOX gain
(0000=0%, 0255=100%)
Send/read Anti VOX gain
(0000=0%, 0255=100%)
Send/read [CONTRAST] level
(0=max. CCW to 255=max. CW)
Send/read BRIGHT level
(0000=0%, 0255=100%)
Read squelch condition (squelch close)
Read squelch condition (squelch open)
Read S-meter level
(0000=S0, 0120=S9, 0241=S9+60 dB)
Read RF power meter
(0000=0 W, 0143=100 W, 0212=200 W)
Read SWR meter
( 0000=SWR1.0, 0048=SWR1.5,
0080=SWR2.0)
Read ALC meter (0000=0, 0120=Max.)
Read COMP meter
(0000=0 dB, 0130=15 dB, 0241=30 dB)
Read VD meter
(0151=44 V, 0180=48 V, 0211=52 V)
Read ID meter
(0000=0 A, 0165=10 A, 0241=15 A)
Preamp OFF
Preamp 1 ON
Preamp 2 ON
AGC OFF selection
AGC FAST selection
AGC MID selection
AGC SLOW selection
Noise blanker OFF
Noise blanker ON
Audio peak filter OFF
Audio peak filter WIDE ON (320 Hz is
selected when SHARP APF is set)
Audio peak filter MID ON (160 Hz is
selected when SHARP APF is set)
Audio peak filter NAR ON (80 Hz is
selected when SHARP APF is set)
Noise reduction OFF
Noise reduction ON
Auto notch function OFF
Auto notch function ON
Repeater bisne OFF
Repeater bisne ON
Tone squelch OFF
Tone squelch ON
Befehl Sub-Befehl
Daten
16
44
00
01
45
00
01
46
00
01
47
00
01
02
48
00
01
4C
00
01
4D
00
01
4E
00
01
16
4F
00
01
50
00
01
53
00
01
55
00
01
02
56
00
01
57
00
01
02
58
00
01
02
17
S. 14-12
18
00
01
19
00
1A
00
S. 14-13
01
S. 14-10
02
S. 14-10
03
00 to 49
04
00 to 13
1
*
Bei CW und betätigter [TRANSMIT]-Taste, bei externer Umschal-
tung auf Senden oder eingeschalteter Break-in-Funktion sendet
der Transceiver CW-Signale, die vom angeschlossenen PC kom-
men.
2
*
Der Power-ON-Befehl (18 01) steht nur im Stand-by-Modus zur
Verfügung.
Beschreibung
Speech compressor OFF
Speech compressor ON
Monitor function OFF
Monitor function ON
VOX function OFF
VOX function ON
BK-IN function OFF
Semi BK-IN function ON
Full BK-IN function ON
Manual notch function OFF
Manual notch function ON
VSC function OFF
VSC function ON
AGC VR function OFF
AGC VR function ON
DIGI-SEL function OFF
DIGI-SEL function ON
Twin peak filter OFF
Twin peak filter ON
Dial lock function OFF
Dial lock function ON
ANT RX-I/O function OFF
ANT RX-I/O function ON
15 kHz roofing filter selection
6 kHz roofing filter selection
3 kHz roofing filter selection
SHARP selection for DSP filter type
SOFT selection for DSP filter type
WIDE selection for manual notch width
MID selection for manual notch width
NAR selection for manual notch width
WIDE selection for SSB transmit
bandwidh
MID selection for SSB transmit
bandwidth
NAR selection for SSB transmit
bandwidth
1
Send CW messages*
Turn ON the transceiver.
2
Turn OFF the transceiver.*
Read the transceiver ID
Send/read memory contents
Send/read band stacking register
contents
Send/read memory keyer contents
Send/read the selected filter width
( SSB, CW, PSK: 00=50 Hz to
40=3600 Hz; RTTY: 00=50 Hz to
31=2700 Hz; AM: 00=200 Hz to 49=10
kHz)
Send/read the selected AGC time
constant
( 00=OFF, 01=0.1/0.3 sec., 13=6.0/8.0
sec.)
