Technical Data

10 Technical Data
Volume flow rate [m³/h]
Power consumption P1 [kW] 3~
Power output P2 [kW] 3~
Number of nozzles Ø 172 mm
Outflow speed [m/s]
Nozzle swivellable to all sides
[degrees]
Net weight [kg]
Pos: 156 /Technische Dokumentation Speck Pumpen/Betriebsanleitung/Technische Daten/Maßzeichnung @ 3\mod_1439965097337_370.docx @ 40120 @ 2 @ 1

10.1 Dimensional drawing

Fig. 24
Fig. 25
48 EN
150-350
3.60
3.00
1
1.80-4.10
± 5
51.50
