Electrical Connection; Monitoring Devices; Explosive Atmosphere In The Collection Reservoir; Transport - Wilo DrainLift WS 40 Einbau- Und Betriebsanleitung

en
2.3

Electrical connection

2.4

Monitoring devices

2.5 Explosive atmosphere in the col-
lection reservoir
2.6

Transport

2.7

Installing/dismantling

38
Safety
ƒ
Ground installation (underground): trained specialist in underground and pipeline
construction
Excavate and prepare the pit, backfill the pit, buoyancy safeguards, connection of
plastic pipes.
ƒ
Maintenance work: Skilled person (trained specialist in plant technology for sanitary
facilities)
Hazards caused by sewage, basic knowledge of lifting units, requirements EN 12056
ƒ
Lifting work: trained specialist for the operation of lifting devices
Lifting equipment, lifting gear, attachment points
ƒ
Personnel have been instructed on locally applicable regulations governing accident
prevention.
ƒ
Personnel have read and understood the installation and operating instructions.
ƒ
Establish the electrical connection according to the instructions for the devices
used.
ƒ
Earth all electrical devices!
The pump chamber is used to collect sewage. In the event of a fault in the system, the
sewage can become backed up to the inlet. In serious cases, the pump chamber can
overflow.
The installation of a high water alarm is recommended to ensure operational reliability.
For increased safety, the high water alarm should be reported via GSM or fieldbus.
Sewage containing faeces can lead to gas accumulations in the tank. These gas accu-
mulations can escape into the operating space and create an explosive atmosphere as a
result of incorrect installation or maintenance work. This atmosphere can ignite and
lead to an explosion. In order to prevent an explosive atmosphere, observe the follow-
ing points:
ƒ
Tank must be undamaged (no cracks, leaks, porous material)! Take any defective
lifting units out of operation.
ƒ
Ensure all connections for the inlet, pressure pipe and aeration and venting are
sealed tightly and in accordance with regulations!
ƒ
Guide the aeration and venting line over the roof.
ƒ
When opening the tank (e.g. during maintenance work), ensure appropriate ex-
change of air!
ƒ
Wear the following protective equipment:
–
Safety footwear
–
Hard hat
ƒ
Locally applicable laws and regulations on work safety and accident prevention must
be complied with.
ƒ
Demarcate and cordon off the working area.
ƒ
Keep unauthorised persons away from the working area.
ƒ
Remove loose components from the product.
ƒ
Only use legally prescribed and approved lifting and hoisting gear.
ƒ
Select the lifting gear based on the prevailing conditions (weather, attachment
point, load, etc.).
ƒ
Always attach the lifting gear to the attachment points.
ƒ
Ensure that the lifting gear is securely attached.
ƒ
Ensure that the hoisting gear is stable.
ƒ
Observe the swivel range.
ƒ
Ensure a second person is present to coordinate the procedure if required (e.g. if the
operator's field of vision is blocked).
ƒ
Standing under suspended loads is not permitted. Do not move suspended loads
over workplaces where people are present.
ƒ
Wear the following protective equipment:
–
Safety footwear
–
Safety gloves for protection against cuts
ƒ
Locally applicable laws and regulations on work safety and accident prevention must
be complied with.
ƒ
Demarcate and cordon off the working area.
ƒ
Remove objects lying around from the work area.
ƒ
Keep unauthorised persons away from the working area.
ƒ
If the weather conditions mean it is no longer possible to work safely, stop work.
WILO SE 05
