1.1 Construction and Function

The 6A40 MagnoFlex Lock is a shuttle lock with a flexible pin and a magnet
integrated in the housing. It serves to secure a suitable liner in the prosthetic
socket. The shuttle lock is installed in the check socket by vacuum forming
and in the definitive socket by lamination. To connect to the distal prosthetic
components, it is equipped with a four-hole connector. The flexible pin is
installed on the liner. When sliding into the prosthetic socket, the magnet in
the MagnoFlex Lock aligns the flexible pin with the opening. This makes it
easier to don the prosthesis.

1.2 Combination possibilities

This prosthetic component is compatible with Ottobock's system of modular
connectors. Functionality with components of other manufacturers that have
compatible modular connectors has not been tested.
Limited combination options for Ottobock components
Designation
Socket adapter
Slide plate
(The 4X314 spacer plate is required in addition.)

2 Intended use

2.1 Indications for use
The product is intended exclusively for lower limb exoprosthetic fittings.
2.2 Area of application
• The maximum approved body weight is specified in the technical data
(see Page 25).
2.3 Environmental conditions
Allowable environmental conditions
Temperature range for use: -10 °C to +60°C
Allowable relative humidity 0 % to 90 %, non-condensing
Unallowable environmental conditions
Mechanical vibrations or impacts
Perspiration, urine, fresh water, salt water, acids
Dust, sand, highly hygroscopic particles (e.g. talcum)
16
Reference number
4R54, 4R77
6A41
