Teileliste - CARDIOSTRONG EX60 Montage- Und Bedienungsanleitung

8.2

Teileliste

Nr. Bezeichnung (ENG)
A MAIN FRAME
A1 SENSOR WIRE 1000mm
A2 MOTOR
A3 SCREW M5xP0.8x12L
A4 SPRING Ø1xØ8.5x48L
A5 SENSOR W IRE HOUSING
A6 SENSOR WIRE 900mm
A7 SCREW M5x10mm
A8 PULLEY Ø30*8
A9 MANGET Ø15*2
A10 AXLE Ø20*154.5L
A11 SCREW M6xP1.30x16L
A12 NUT M10xP1.25-LHx1OT
A13 NYLON M6X5.5T
A14 BEARING 6004 2ZZ
A15 PRESSING PLARE
A16 SCREW M8xP1.25x20L
A17 BEARING HOUSING
A18 BEARING 6000 2ZZ
A19 WASHER Ø6.5xØ13x2T
A20 SCREW M6x10L
A21 SPRING Ø20xØ4x12N
A22 NUT M6 Ø14.4x30L
A23 SCREW M6xP1.0x60L
A24 TURNING PLATE
A25 PIPE
A26 NUT M10xP1.25x10T
A27 DECORDATION COVE
A28 DC W IRE 1000L
A29 BELT 900J6
A30 MAGNETIC FLYWHEEL Ø400
32W11KG
Anz. Nr. Bezeichnung (ENG)
1 A31 AXLE 3/8" *26* Ø10*128L
1 A32 BEARING 6300 2RS
1 A33 NUT 3/8"-26*3.8T
2 A34 BUSH Ø10xØ15.8x9mm
1 A35 WASHER Ø8xØ19x2T
1 A36 SCREW 2/8"-26x7T
1 A37 PLATE COVER
2 A38 SCREW ST3.5x16L
1 A39 MAGNETIC HOUSING
1 A40 SCREW M8xP1.25x55LxS17
1 A41 NUT M8x7T
4 A42 MAIN CHAIN COVER (L)
1 A43 MAIN CHAIN COVER (R)
4 A44 SCREW 3/4 ¾
2 A45 SCREW
1 A46 WASHER Ø8xØ16x2T
1 A47 NUT M8x7T
1 A48 WASHER Ø5.5xØ12x2T
2 A49 BEARING 6000 2RS
1 A50 EVA PAD STICKER 20X60X1.5T
1 A51 CLIP Ø18.5xØ22.5x1T
1 A52 WASHER Ø20.3xØ30x0.5T
1 A53 WAVE WASHER Ø20.5xØ30x0.3T
1 A54 WAVE WASHER Ø10.2xØ13x0.3T
2 A55 FIXING SHEET
2 A56 SCREW M8x55LxS25L
1 A57 NUT M8x6T
2 B CENTRAL SUPPORT TUBE
1 B 1 SENSOR WIRE 800L
1 B2 SENSOR WIRE 350L
1 B3 END CAP
B4 SCREW M5x16L
Anz.
1
1
3
1
1
2
2
6
1
1
1
1
1
12
8
1
1
2
1
6
1
1
2
2
1
1
1
1
1
2
2
2
41
