5.

Filter/pump installation

The filter/pump is positioned at least 3.5 m from the edge of the pool. The water temperature must
not exceed 35 °C or go under 0 °C .
Disconnect the plug before starting to do any work.
BEWARE:
Always place the sand filter system in level with the pool bottom, so that the water can
flow naturally towards the pump. Is it used with an in-ground pool, you have to place
the sand filter system correspondingly lower into a shaft/pit in the ground, so the water
can flow by itself into the pump. Be sure that the shaft/pit stays dry. There should be an
outlet/drain to lead the water out of the shaft/pit.
5.1

Filterinstallation

1. Make sure that the drain plug (8) is screwed in the filter tank (5).
2. Insert the stand pipe (6) including the filter screen (7) on the floor of the filter tank (5). Make
sure that the stand pipe is located in the middle of the tank (figure 2 and 3).
3. Fill up the filter tank with the included filterballs. If you are using filter sand place the centralizer
(9) on the top of the container to provide sand getting into the central pipe during filling (figure
4).
Page 34
Figure 2
MV-1080-09-2016 . Swim & Fun Scandinavia . info@swim-fun.dk . www.swim-fun.com
Figure 4
© All rights reserved Swim & Fun Scandinavia ApS 2016
Figure 3
