1.3 Limited warranty
The manufacturer guarantees safe operation and product liability based on the following specific
conditions:
Sand filter system installed and used in accordance with the manual's instructions.
Use only original spare parts. Wear include:
• O-rings
• Manometer
• Leaks occurred between seals and hoses and hose connections in general.
NOTE:
Always make sure that the hoses on both suction and pressure sides are closed, so the
water never can get into the pump itself, if loosen the filter hose couplings. There is no
warranty for damages caused by flooding of the pump.

2. Specifications

7-way valve, filter pump TÜV / GS, filter vessel, connection Ø 32/38 mm, base plate
Model
Flow rate:
Connection:
Amount of filterballs:
Amount of Sand:
Pool size:
Filter pump:
3.

Connecting to power source

The pump must be connected to the electric network by a 30 mA differential switch. Always discon-
nect the pump from the electric network before carrying out any kind of operation on the filter or
pump.
NOTE:
Prior to assembling and using this product, carefully read and adhere to all caution and
important notices located throughout this manual. Failure to comply with these instruc-
tions may damage to the product or cause serious personal injury or death.
Page 32
MV-1080-09-2016 . Swim & Fun Scandinavia . info@swim-fun.dk . www.swim-fun.com
1080
3,8 m³/h at 0,4 bar working pressure
230 V, max. 200 W
max. 280 g
max. 10 kg
max. 19 m³
with prefilter, not self-priming
© All rights reserved Swim & Fun Scandinavia ApS 2016
