LEVELLING
Adjust the floor-mounted feet (A) to level the appli-
ance.

ASSEMBLY APPLIANCES IN BANKS

To assemble appliances in
banks (side by side) proceed
as described below.
1 - Pull off the knob (A).
2 - Undo the screws (C) and
remove the control pan-
els (B).
3 - Apply masking tape to
the edges to be placed
side by side.
4 - Apply food-approved
sealant to the edges to
be placed side by side.
5 - Place the appliances
side by side.
6 - Connect the appliance using the screws and
nuts (D-E).
For appliances installed in banks, an optional kit is
available with the supporting frame and some trims.
C
A B
C
7 - Remove the excess sealant and the masking
tape.
8 - Replace the control panels (B) and the knobs
(A) on completion of the operation.
