Set-up/installation / Maintenance

7. Set-up/installation

FLOW F series submersible pumps are for transportable installation only.
Set up: Set up the pump on solid ground. When setting up in muddy or sandy
ground, the pump should be operated while suspended in the medium, by a rope or
chain, or be placed on a large base plate. Do not suspend the pump by the cable.
The pump is not suitable for permanent fixed installation as it is not in compliance
with DIN EN 12056/12050 regulations.
Moisture sensor for automatic operation:
When the water level reaches the On-sensor (see page 22, figure 3) (min. level
20 mm) the pump automatically starts, and pumps the water until the level falls
below the Off-sensor (see page 22, figure 3), at which point the pump is automati-
cally turned off (the pump will continue to run for approx. 2 seconds after switch-off).
The sensors are fixed in position and must not be changed. Doing so will invali-
date the pump warranty.
A built-in time delay will prevent the pump from operating for approx. 20 - 30
seconds after start-up or after re-connection following disruption to the power
supply.

8. Maintenance

Before carrying out any work, disconnect the pump from the electrical system and
secure it from being accidentally switched on again. Check the discharge pipe line
for damage. To ensure that the pump operates smoothly, we recommend regular
cleaning of the inlet strainer to remove fibres and other clinging material.
If there are problems, please contact your GC partner.
