Chapter 4
This section explains how to insert the batteries into the Power Manager
and provides a list of approved power sources to power the SprintPack
Li-Ion Power System.

Inserting / Removing SprintPack Batteries

To Remove a SprintPack Battery
Push up on the desired Locking Latch, then slide battery out.
18415-001, Rev. E
- C
HARGING THE
To Insert a SprintPack Battery
1) Align the battery as shown into
2) Gently push up the desired
Operator's Manual - SprintPack™
S
PRINT
Locking Latches
(right and left)
the SprintPack Power Manager.
Locking Latch and slide the
battery into the Power Manager.
The battery will "click" when it is
locked in place.
P
ACK
4-1
