Testboy TV 465
H. Communication
The instrument can communicate with the PC SW TV 465 PC software. The following
actions are supported:

Saved results can be downloaded and stored to a PC.

Checkbox results can be downloaded and stored to the PC.

Custom Auto sequences can be uploaded to the instrument.
A special communication program on the PC automatically identifies the instrument and
enables data transfer between the instrument and the PC.
There are two communication interfaces available on the instrument: USB or RS 232.
The instrument automatically selects the communication mode according to the detected
interface. USB interface has priority.
How to transfer stored data:

RS 232 communication: connect a PC COM port to the instrument PS/2 connector
using the PS/2 - RS232 serial communication cable.

USB communication: connect a PC USB port to the instrument USB connector
using the USB interface cable.

Switch on the PC and the instrument.

Run the PC SW TV 465 program.

The PC and the instrument will automatically recognize each other.

The instrument is prepared to upload / download data to the PC.
Note:

USB drivers should be installed on PC before using the USB interface. Refer to
USB installation instructions available on installation CD.
119
