Testboy TV 465
o

Substitute leakage current

Range
0.00 mA  9.99 mA
10.0 mA  20.0 mA
Open circuit voltage .................. <50 V AC at rated mains voltage
Short circuit current ................... <2,5 mA
Pass levels:
Substitute leakage .................... 0.25 mA, 0.50 mA, 0.75 mA, 1.00 mA, 1.50 mA, 2.00 mA,
Substitute leakage - P ............... 0.25 mA, 0.50 mA, 0.75 mA, 1.00 mA, 1.50 mA, 2,00 mA,
Test duration ............................. 2 s, 3 s, 5 s, 10 s, 30 s, 60 s, 120 s, ∞
Displayed current ...................... calculated to appliance nominal mains supply voltage
Test terminals:
Sub. leakage
Sub. leakage-P
o

Polarity test

Test voltage .............................. <50 V AC
Detects ...................................... PASS, L OPEN, N OPEN, PE OPEN, L-N CROSS,
Test terminals:
Polarity
o

Voltage measurement

Range
0  300 V
Result type ................................ True r.m.s. (trms)
Nominal frequency range .......... 0 Hz, 50 Hz  60 Hz
Frequency accuracy.................. Indication only
Test terminals:
Voltage TRMS
Resolution
0.01 mA
0.1 mA
2,25 mA, 2.50 mA, 3.50 mA, 4.00 mA, 4.50 mA, 5.00 mA,
5.50 mA, 6.00 mA, 7.00 mA, 8.00 mA,9.00 mA, 10.0 mA,
15.0 mA, ---- mA
--- mA
(230 V) x 1.06.
LN (mains test socket) ↔ PE ( mains test socket)
LN (mains test socket) ↔ S/EB1 (probe)
MULTIPLE FAULT.
Main test socket ↔ IEC test socket
Resolution
1 V
IEC test socket
Accuracy
(5 % of reading + 3 digits)
Accuracy
(2 % of reading + 2 digits)
80
Technical specifications
