Testboy TV 465
D. Main menu and test modes
o

Instrument Main menu

From the Main menu of the instrument there are five instrument operation modes, Help
and Setup that can be selected:
Keys:
 / 
Select one of the following menu items:
TAB <VDE ORGANIZER> pre-programmed test sequences according to the
<SINGLE TEST> individual tests, see chapter 5 Single test;
<CUSTOM AUTOTEST> user defined pre-programmed sequences, see
<SIMPLE TEST> simple pre-programmed sequences, see chapter 6.3
<CODE AUTOTEST> code-based test sequences, suitable for working
<HELP> help screens;
<SETUP> menu for setup of the instrument/ help screens, see chapter 4.7
TEST Confirms selection.
o

VDE Organizer menu

This menu offers creation and performing of VDE compatible test sequences. The
sequence setup and its parameters are the same as suggested in the VDE 0701-0702
standard. After an autotest sequence has been created in the VDE organizer, it can be run
as an autotest or stored in the Custom autotest menu.
See chapter 6.1 VDE organizer setup menu for more information.
Figure 0.8: Instrument Main menu
VDE 0701-0702 norm, see chapter 6.1 VDE organizer setup menu ;
chapter 6.2 Custom autotest ;
Simple test
with barcodes and RFID tags, see chapter 6.4 Code autotest;
Setup menu;
Figure 0.9: VDE organizer menu

Main menu and test modes

83
