D – Dust container
If you find out that the suction performance of the vacuum cleaner is reduced, make sure
that the dust container is not full and if necessary, empty it. Press container lock button E2
and then remove container D from the extension adapter E (Fig. 8). The suction chamber
lid D1, filter D2 and separator D3 pull it out of the container. Clean all parts in running
lukewarm water, e.g. using a cloth or a soft brush and let it dry completely. Re-assemble
individual parts in the opposite direction.
Storage
Store the appliance thoroughly clean on a dry, dustless place out of reach of children and
persons sui juris. Do not put the assembled rod vacuum cleaner on an uneven surface!
The cleaner must be placed on a flat surface where there is no danger of knocking over.
Insert one of the accessories (flexible joint G7, upholstery nozzle G3, crevice nozzle G2)
into charging stand H.
V. MAINTENANCE
Before any maintenance, disconnect the charging adapter from the appliance. Clean the
vacuum cleaner surface and the charging adapter with a soft damp cloth; do not use abrasive
and aggressive cleaning agents! Never dry plastic moldings over a heat source (e.g. heater,
electric/gas stove). Check and clean the vacuum channel of floor nozzle brush and the main
stick body (above the reservoir) occasionally. Remove the blockage and take out any waste.
Floor nozzle F, rotary small turbobrush G1
Wipe the floor nozzle with a damp cloth. After every vacuuming, check if any dirt is trapped
in the rotating brush. If the brush is unclean, please remove it from the floor nozzle
according to Fig. 9, 10. Now you may easily clean the brush (rinse it in running water).
After wash the roller brush, please dry the shaft at end of brush (milky plastic location)
with damp cloth to avoid rusting. Warning: Do not water the floor nozzle in running water
directly, it will damage motor and PCB. After the maintenance, apply a reverse procedure
to install the brush in the nozzle and secure it.
Release the two arrest latches F3 on the bottom side of the nozzle in the direction of the
arrow and remove the cover (Fig. 11). Release the holder F4, then take out the hose from
groove to clean it. Clean the space with a suitable tool (e.g. tweezers). After cleaning,
reassemble it.
Accessories (G)
After any vacuuming it is recommended to check visually the brushes or collectors for
possible impurities. If there are some impurities, remove them.
Other parts (C, E)
extension adapter/suction tube C and extension adapter E with a wet cloth. Allow all the
parts to dry out properly before re-use.
HEPA filter, separator and seal ring
Remove separator B2 and seal ring B3 from the HEPA filter (Fig. 8). Rinse the separator
and seal ring in running water. Clean the HEPA filter by knocking or blowing (for sanitary
reasons, we recommend doing this outside residential premises). If the HEPA filter is very
dirty, you can rinse it under running lukewarm water (i.e. tilt the HEPA filter to the side while
holding it so that the "dirty" fanfolded side is pointing upwards, water can flow along the
