II. EQUIPMENT AND ACCESSORIES OF VACUUM CLEANER (Fig. 1)
A – vacuum cleaner
A1 – button
A2 – operation signal lights and charging
A3 – vacuum cleaner lid lock button
B – dust container
B1 – HEPA filter
B2 – foam micro–filter
B3 – separator
C – extension adapter/suction tube = upper par
C1 – button
C2 – button to set the suction power
D – Dust container
D1 – suction chamber lid
D2 – filtr
E – extension adapter = lower part
E1 – adapter C lock buttons
E2 – container D lock buttons
F – floor nozzle with rotation brush and flexible joint
F1 – brush lock buttons
F2 – rotation brush
G – accessories
G1 – special mattress and upholstery rotary small turbobrush
G2 – crevice nozzle with retractable brush
G3 – upholstery nozzle with retractable brush
G4 – triangular nozzle
G5 – flat brush
G6 – flexible extension hose
G7 – flexible joint bendable to sides
H – charging stand
H1 – power supply socket
I – power adapter
III. VACUUM CLEANER PREPARATION
Remove all packing material, take out the vacuum cleaner and the accessories. Remove all
possible adhesion foils, stick-on labels or paper from the appliance.
VACUUM CLEANER ASSEMBLY
When assembling the vacuum cleaner, follow the procedure indicated in Fig. 1, 2.
For disassembly, proceed the other way round and release the locks.
Fixing vacuum cleaner into adapter
Put vacuum cleaner A to adapter E with the suction vent and they tilt the vacuum cleaner
to the aperture to the maximum position (you will hear a snapping sound), (Fig. 2).
A4 – handle
A5 – button to set the suction power
B4 – tilting handle
B5 – container locking button
B6 – bottom lock button
C3 – adaptor lock button
C4 – tilting plug
D3 – separator
D4 – tilting handle
E3 – opening to attach
F3 – cover lock button
F4 – holder suction hose
