OPERATION

After connecting the device to the mains it is ready for operation. The display indicates the last operating
mode. The operating modes can be selected by means of the display and the control buttons. All settings
remain stored even if the device is disconnected from the mains. The device can be operated in stand-alone
mode via the control board and the EUROLITE IR-7 remote control or in DMX-controlled mode via any
commercial DMX controller.
Operating buttons
Button
MENU
ENTER
UP
DOWN

Menu structure

Mode
DMX mode
Slave mode
Preset colors
Automatic mode
Sound control
Running speed in
automatic and sound-
controlled mode
Microphone sensitivity
for sound control
Sound control
„silent scene"
IR remote control
( * ) Color presets
C01 Red
C02 Green
C03 Blue
C04 White
C05
Amber
C06 Red + Green
C07 Red + Blue + Amber
C08 Red + White
Function
Selects the operating mode or returns to the initial screen.
Activates a value to be modified or saves a value when modifying.
Selects the next menu item or increases values when modifying.
Selects the previous menu item or decreases values when modifying.
Display
23CH
Addr 7CH
4CH
SLAV SLAU
Cxx C01 – C15
Auto Au01 – Au03
Soun So01 – So03
SPEE SP01 – SP09
SEnS SE01 – SE09
on
SILE
oFF
on
InFr
oFF
C09
C10
C11
C12
C13
C14
C15
d001-490 23-channel mode and start address
d001-506 7-channel mode and start address
d001-509 4-channel mode and start address
Slave mode
Constant lighting in one of 15 colors
Automatic programs
Sound-controlled programs
Program running speed slow > fast
Microphone sensitivity low > high
LEDs off if there is no music signal
LEDs remain on if there is no music signal
IR remote control on
IR remote control off
Green + Blue
Green + White
Blue + White
Red + Green + Blue
Red + Green + White
Green + Blue + White
Red + Green + Blue + White + Amber
26/36
